| 代 号 |
螺 纹 E |
胶 管 HOSE BORE |
尺 寸 DIMENSIONS |
| PART NO. |
THREAD E |
公称内径 DN |
标号 DASH |
A |
L |
S1 |
d |
| 12611A-04-04PO |
G1/4"X19 |
6 |
04 |
20 |
38 |
19 |
4.3 |
| 12611A-06-06PO |
G3/8"X19 |
10 |
06 |
24 |
45.5 |
22 |
7.5 |
| 12611A-08-08PO |
G1/2"X14 |
12 |
08 |
28.5 |
54 |
27 |
9.9 |
| 12611A-12-12PO |
G3/4"X14 |
20 |
12 |
32 |
69.5 |
32 |
15.5 |
| |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
