| 代 号 |
螺 纹 E |
胶 管 HOSE BORE |
尺 寸 DIMENSIONS |
| PART NO. |
THREAD E |
公称内径 DN |
标号 DASH |
|
A |
C |
S1 |
|
| 15611-02-03 |
Z1/8"X27 |
5 |
03 |
|
22.5 |
10.5 |
12 |
|
| 15611-02-04 |
Z1/8"X27 |
6 |
04 |
|
22.5 |
10.5 |
12 |
|
| 15611-04-03 |
Z1/4"X18 |
5 |
03 |
|
27.5 |
15 |
17 |
|
| 15611-04-04 |
Z1/4"X18 |
6 |
04 |
|
28 |
15 |
17 |
|
| 15611-04-05 |
Z1/4"X18 |
8 |
05 |
|
28 |
15 |
17 |
|
| 15611-04-06 |
Z1/4"X18 |
10 |
06 |
|
27 |
15 |
17 |
|
| 15611-06-04 |
Z3/8"X18 |
6 |
04 |
|
28 |
16 |
19 |
|
| 15611-06-05 |
Z3/8"X18 |
8 |
05 |
|
28 |
16 |
19 |
|
| 15611-06-06 |
Z3/8"X18 |
10 |
06 |
|
30 |
16 |
19 |
|
| 15611-06-08 |
Z3/8"X18 |
12 |
08 |
|
30.5 |
16 |
19 |
|
| 15611-08-06 |
Z1/2"X14 |
10 |
06 |
|
34.5 |
19.5 |
22 |
|
| 15611-08-08 |
Z1/2"X14 |
12 |
08 |
|
34.5 |
19.5 |
22 |
|
| 15611-08-10 |
Z1/2"X14 |
16 |
10 |
|
36 |
19.5 |
22 |
|
| 15611-12-08 |
Z3/4"X14 |
12 |
08 |
|
37.5 |
19.5 |
27 |
|
| 15611-12-10 |
Z3/4"X14 |
16 |
10 |
|
38 |
19.5 |
27 |
|
| 15611-12-12 |
Z3/4"X14 |
20 |
12 |
|
38.5 |
19.5 |
27 |
|
| 15611-12-16 |
Z3/4"X14 |
25 |
16 |
|
39.5 |
19.5 |
32 |
|
| 15611-16-10 |
Z1"X11.5 |
16 |
10 |
|
45 |
25.5 |
36 |
|
| 15611-16-12 |
Z1"X11.5 |
20 |
12 |
|
45 |
25.5 |
36 |
|
| 15611-16-16 |
Z1"X11.5 |
25 |
16 |
|
44.5 |
25.5 |
36 |
|
| |
|
|
|
|
|
|
|
|
|
|
|
