| PART NO. |
THREAD |
DIMENSIONS |
| E |
F |
A |
B |
S1 |
| 7N9-02PK |
Z1/8"X27 |
Z1/8"X27 |
20 |
20 |
16 |
| 7N9-02-04PK |
Z1/8"X27 |
Z1/4"X18 |
20 |
22.5 |
19 |
| 7N9-04PK |
Z1/4"X18 |
Z1/4"X18 |
22.5 |
22.5 |
19 |
| 7N9-04-06PK |
Z1/4"X18 |
Z3/8"X18 |
25 |
26 |
24 |
| 7N9-06PK |
Z3/8"X18 |
Z3/8"X18 |
26 |
26 |
24 |
| 7N9-06-08PK |
Z3/8"X18 |
Z1/2"X14 |
26 |
31 |
27 |
| 7N9-08PK |
Z1/2"X14 |
Z1/2"X14 |
31 |
31 |
27 |
| 7N9-08-12PK |
Z1/2"X14 |
Z3/4"X14 |
34 |
34 |
33 |
| 7N9-12PK |
Z3/4"X14 |
Z3/4"X14 |
34 |
34 |
33 |
| 7N9-12-16PK |
Z3/4"X14 |
Z1"X11.5 |
42 |
42 |
41 |
| 7N9-16PK |
Z1"X11.5 |
Z1"X11.5 |
42 |
42 |
41 |
| 7N9-20PK |
Z1.1/4"X11.5 |
Z1.1/4"X11.5 |
48 |
48 |
50 |
| 7N9-24PK |
Z1.1/2"X11.5 |
Z1.1/2"X11.5 |
53 |
53 |
60 |
| 7N9-32PK |
Z2"X11.5 |
Z2"X11.5 |
62 |
62 |
70 |
| |
|
|
|
|
|
|
