| PART NO. |
THREAD |
DIMENSIONS |
| E |
F |
G |
A,C |
B |
S1 |
S2 |
S3 |
| EB-02 |
G1/8"X28 |
G1/8"X28 |
G1/8"X28 |
5.5 |
20 |
11 |
14 |
14 |
| EB-04 |
G1/4"X19 |
G1/4"X19 |
G1/4"X19 |
5.5 |
24.5 |
14 |
19 |
19 |
| EB-06 |
G3/8"X19 |
G3/8"X19 |
G3/8"X19 |
6.3 |
27.5 |
16 |
22 |
22 |
| EB-08 |
G1/2"X14 |
G1/2"X14 |
G1/2"X14 |
7.5 |
34.5 |
22 |
27 |
27 |
| EB-10 |
G5/8"X14 |
G5/8"X14 |
G5/8"X14 |
9.5 |
35 |
22 |
30 |
30 |
| EB-12 |
G3/4"X14 |
G3/4"X14 |
G3/4"X14 |
10.9 |
40 |
27 |
32 |
32 |
| EB-16 |
G1"X11 |
G1"X11 |
G1"X11 |
11.7 |
46 |
33 |
41 |
41 |
| EB-20 |
G1.1/4"X11 |
G1.1/4"X11 |
G1.1/4"X11 |
11 |
50.5 |
41 |
50 |
50 |
| EB-24 |
G1.1/2"X11 |
G1.1/2"X11 |
G1.1/2"X11 |
13 |
57.5 |
48 |
55 |
55 |
| EB-32 |
G2"X11 |
G2"X11 |
G2"X11 |
16 |
68 |
63 |
70 |
70 |
| |
|
|
|
|
|
|
|
|
|
