PART NO.

      THREAD

            DIMENSIONS

E

F

A

B

L

S1

S2

2NB-02

Z1/8"X27

G1/8"X28

10.5

5.5

25.5

12

14

2NB-02-04

Z1/8"X27

G1/4"X19

10.5

5.5

27

14

19

2NB-04-02

Z1/4"X18

G1/8"X28

15

5.5

30

17

14

2NB-04

Z1/4"X18

G1/4"X19

15

5.5

31

17

19

2NB-04-06

Z1/4"X18

G3/8"X19

15

6.3

32.5

17

22

2NB-04-08

Z1/4"X18

G1/2"X14

15

7.5

35

19

27

2NB-06

Z3/8"X18

G3/8"X19

16

6.3

33.5

19

22

2NB-06-04

Z3/8"X18

G1/4"X19

16

5.5

33

19

19

2NB-06-08

Z3/8"X18

G1/2"X14

16

7.5

36

19

27

2NB-08

Z1/2"X14

G1/2"X14

19.5

7.5

41

22

27

2NB-08-04

Z1/2"X14

G1/4"X19

19.5

5.5

38.5

22

19

2NB-08-06

Z1/2"X14

G3/8"X19

19.5

6.3

39.5

22

24

2NB-08-12

Z1/2"X14

G3/4"X14

19.5

10.9

44.5

27

32

2NB-12

Z3/4"X14

G3/4"X14

19.5

10.9

44.5

30

32

2NB-12-06

Z3/4"X14

G3/8"X19

19.5

6.3

41.7

30

22

2NB-12-08

Z3/4"X14

G1/2"X14

19.5

7.5

43.5

30

27

2NB-12-16

Z3/4"X14

G1"X11

19.5

11.7

46.5

32

41

2NB-16-12

Z1"X11.5

G3/4"X14

21.5

10.9

51.5

36

32

2NB-16

Z1"X11.5

G1"X11

25.5

11.7

52.5

36

41

2NB-20

Z1.1/4"X11.5

G1.1/4"X11

26.5

11

59.5

46

50

2NB-24

Z1.1/2"X11.5

G1.1/2"X11

27.5

13

61.5

50

55

2NB-32

Z2"X11.5

G2"X11

27.5

16

66.5

65

70
