PART NO.
|
THREAD |
TUBE O.D. |
DIMENSIONS |
| E |
F |
G |
D1,D2,D3 |
A |
B |
C |
S1 |
S2,S3,S4 |
| AQ-14 |
M14X1.5 |
M14X1.5 |
M14X1.5 |
8 |
30.2 |
30.5 |
30.2 |
14 |
17 |
| AQ-16 |
M16X1.5 |
M16X1.5 |
M16X1.5 |
10 |
32 |
32 |
32 |
16 |
19 |
| AQ-18 |
M18X1.5 |
M18X1.5 |
M18X1.5 |
12 |
34 |
34 |
34 |
19 |
22 |
| AQ-22 |
M22X1.5 |
M22X1.5 |
M22X1.5 |
14 |
37.5 |
37.5 |
37.5 |
22 |
27 |
| AQ-27 |
M27X1.5 |
M27X1.5 |
M27X1.5 |
18 |
41.5 |
41.5 |
41.5 |
27 |
32 |
| AQ-30 |
M30X1.5 |
M30X1.5 |
M30X1.5 |
20 |
45.8 |
45.8 |
45.8 |
30 |
36 |
| AQ-33 |
M33X2 |
M33X2 |
M33X2 |
22 |
49.5 |
49.5 |
49.5 |
33 |
41 |
Note: In case if you are interested to order the adapter in complete set with sleeve and nut ,it is necessary to insert suffix "RN" after our part no.,for example AQ-18RN. |
|
|
