PART NO. |
THREAD |
O-RING |
DIMENSIONS |
| E/F/G |
E/F/G |
A |
B |
C |
S1 |
S2 |
| AE6EE-12 |
M12x1.25 |
8x1.9 |
20.5 |
44.5 |
20.5 |
12 |
17 |
| AE6EE-14 |
M14x1.5 |
10x1.9 |
22.5 |
46.5 |
22.5 |
14 |
19 |
| AE6EE-16 |
M16x1.5 |
11x1.9 |
24 |
48 |
24 |
17 |
22 |
| AE6EE-18 |
M18x1.5 |
13x1.9 |
26 |
50 |
26 |
19 |
24 |
| AE6EE-22 |
M22x1.5 |
16x2.4 |
29 |
54 |
29 |
22 |
30 |
| AE6EE-27 |
M27x1.5 |
20x2.4 |
32.5 |
58.5 |
32.5 |
27 |
36 |
| AE6EE-30 |
M30x1.5 |
24x2.4 |
35.5 |
61.5 |
32.5 |
30 |
41 |
| AE6EE-36 |
M36x2 |
30x3.1 |
42 |
71 |
42 |
36 |
46 |
| AE6EE-39 |
M39x2 |
32x3.1 |
47.5 |
76 |
47.5 |
41 |
50 |
| AE6EE-42 |
M42x2 |
35x3.1 |
49.5 |
78 |
49.5 |
41 |
50 |
| AE6EE-45 |
M45x2 |
38x3.1 |
52.5 |
81 |
52.5 |
46 |
55 |
| |
In case if you are interested to order the adapter with lock nut,please insert suffix"LN" after our part
NO.,for example AEE6E-30LN. |
|
|
