| PART NO. |
FLANGE SIZE |
HOSE BORE |
DIMENSIONS |
| DN |
DASH |
A |
C |
D |
H |
L |
| 87343-12-12 |
3/4" |
20 |
12 |
85.8 |
38.1 |
31.7 |
28.9 |
7 |
| 87393-16-12 |
1" |
20 |
12 |
85.8 |
44.4 |
38 |
28.9 |
8 |
| 87343-16-16 |
1" |
25 |
16 |
96.1 |
44.4 |
38 |
29.7 |
8 |
| 87343-20-16 |
1.1/4" |
25 |
16 |
96.1 |
50.8 |
43 |
29.7 |
8 |
| 87343-20-20 |
1.1/4" |
32 |
20 |
108.8 |
50.8 |
43 |
33.8 |
8 |
| 87343-24-20 |
1.1/2" |
32 |
20 |
110.2 |
60.3 |
50 |
35.2 |
8 |
| 87343-24-24 |
1.1/2" |
40 |
24 |
123.7 |
60.3 |
50 |
39.1 |
8 |
| 87343-32-24 |
2" |
40 |
24 |
123.7 |
71.4 |
62 |
39.1 |
9.53 |
| 87343-32-32 |
2" |
50 |
32 |
148.3 |
71.4 |
62 |
46.3 |
9.53 |
| |
|
|
|
|
|
|
|
|
|
|
