| PART NO. |
BOLT |
HOSE BORE |
DIMENSIONS |
| DN |
DASH |
A |
d |
D |
H |
| 70011-10-03 |
M10 X 1 |
5 |
03 |
14.5 |
10 |
19 |
11 |
| 70011-10-04 |
M10 X 1 |
6 |
04 |
17 |
10 |
19 |
11 |
| 70011-12-04 |
M12 X 1.5 |
6 |
04 |
20.5 |
12 |
20 |
12 |
| 70011-12-05 |
M12 X 1.5 |
8 |
05 |
20.5 |
12 |
20 |
12 |
| 70011-12-06 |
M12 X 1.5 |
10 |
06 |
20.5 |
12 |
20 |
12 |
| 70011-14-04 |
M14 X 1.5 |
6 |
04 |
21 |
14 |
24 |
14 |
| 70011-14-05 |
M14 X 1.5 |
8 |
05 |
21 |
14 |
24 |
14 |
| 70011-14-06 |
M14 X 1.5 |
10 |
06 |
21 |
14 |
24 |
14 |
| 70011-16-04 |
M16 X 1.5 |
6 |
04 |
20.5 |
16 |
28 |
16 |
| 70011-16-05 |
M16 X 1.5 |
8 |
05 |
20.5 |
16 |
28 |
16 |
| 70011-16-06 |
M16 X 1.5 |
10 |
06 |
20.5 |
16 |
28 |
16 |
| 70011-18-04 |
M18 X 1.5 |
6 |
04 |
23 |
18 |
32 |
20 |
| 70011-18-05 |
M18 X 1.5 |
8 |
05 |
24 |
18 |
32 |
20 |
| 70011-18-06 |
M18 X 1.5 |
10 |
06 |
24 |
18 |
32 |
20 |
| 70011-18-08 |
M18 X 1.5 |
12 |
08 |
2405 |
18 |
32 |
20 |
| 70011-20-08 |
M20 X 1.5 |
12 |
08 |
30 |
20 |
36 |
22 |
| 70011-22-06 |
M22 X 1.5 |
10 |
06 |
28.1 |
22 |
39 |
25 |
| 70011-22-08 |
M22 X 1.5 |
12 |
08 |
28.5 |
22 |
39 |
25 |
| 70011-22-10 |
M22 X 1.5 |
16 |
10 |
28 |
22 |
39 |
25 |
| 70011-26-12 |
M26 X 1.5 |
20 |
12 |
32.5 |
26.2 |
46 |
30 |
| 70011-30-16 |
M30 X 1.5 |
25 |
16 |
37 |
30.2 |
54 |
36 |
| 70011-30-20 |
M30 X 1.5 |
32 |
20 |
40 |
30.2 |
54 |
36 |
| |
|
|
|
|
|
|
|
|
|
