| PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
| DN |
DASH |
A |
C |
S1 |
| 15611-02-04PO |
Z 1/8"X27 |
6 |
04 |
16.5 |
10.5 |
12 |
| 15611-04-04PO |
Z 1/4"X18 |
6 |
04 |
21.1 |
15 |
14 |
| 15611-04-06PO |
Z 1/4"X18 |
10 |
06 |
22.6 |
15 |
14 |
| 15611-06-06PO |
Z 3/8"X18 |
10 |
06 |
22.6 |
16 |
19 |
| 15611-06-08PO |
Z 3/8"X18 |
12 |
08 |
22.6 |
16 |
19 |
| 15611-08-08PO |
Z 1/2"X14 |
12 |
08 |
29 |
19.5 |
22 |
| 15611-08-10PO |
Z 1/2"X14 |
16 |
10 |
29 |
19.5 |
22 |
| 15611-12-12PO |
Z 3/4"X14 |
20 |
12 |
30.7 |
19.5 |
27 |
| |
|
|
|
|
|
|
|
|
|
