| PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
| DN |
DASH |
A |
C |
S1 |
S2 |
| 10811L-12-04 |
M12X1.5 |
6 |
04 |
46 |
34 |
17 |
17 |
| 10811L-12-04A |
M12X1 |
6 |
04 |
44.5 |
32.5 |
17 |
17 |
| 10811L-14-04 |
M14X1.5 |
6 |
04 |
46 |
34 |
17 |
19 |
| 10811L-14-06 |
M14X1.5 |
10 |
06 |
46.5 |
34 |
17 |
19 |
| 10811L-16-04 |
M16X1.5 |
6 |
04 |
46.5 |
34 |
19 |
22 |
| 10811L-16-06 |
M16X1.5 |
10 |
06 |
46.5 |
34 |
22 |
22 |
| 10811L-20-06 |
M20X1.5 |
10 |
6 |
57 |
40 |
27 |
27 |
| 10811L-20-08 |
M20X1.5 |
12 |
08 |
57.5 |
40 |
27 |
27 |
| 10811L-22-08 |
M22X1.5 |
12 |
08 |
62.5 |
45 |
27 |
27 |
| |
|
|
|
|
|
|
|
| |
|
|
